Honeywell DP1030A5014 24 Vac 1 Pole Definite Contactor

Hover over image to zoom

  • Image 1
SKU:
HONE462
Availability:
Usually ships within 24 hours

 Product Description

These electromagnetically-operated Definite Purpose Contactors provide switching for starting induction motors.

Features

  • Meets ARI-780 Standard at started ratings (500,000 cycle mechanical life, 200,000 cycle electrical life and 10,000 cycle recycle life); the most demanding ARI requirement.
  • Silver cadmium oxide contacts provide long life under demanding duty cycles.
  • Low profile design allows for more wiring room.
  • Multiple mounting holes and slots for convenient, interchangeable mounting with most competitive devices.

Product Specifications

Application
PowerPro Definite Purpose Contactor
Dimensions (in.)
2.2 in. high x 2.5 in. wide x 3.31 in. deep
Dimensions (mm)
56 mm high x 59 mm wide x 84 mm deep
Frequency
50 Hz; 60 Hz
Approvals, Underwriters Laboratories Inc.
Component Recognized: File No. 14480, Guide No. NLDX2
Approvals, Canadian Standards Association
Certified: File No. LR6535
Electrical Connections
lug connectors
Temperature Ratings (C)
-20 C to +65 C
Temperature Ratings (F)
-4 F to +149 F
Switching
SPST
Contact Ratings (AFL)
30 A @ 240/277 Vac
Contact Ratings (resistive)
48 A @ 240/277 Vac
Poles
1
Contact Connections (coil)
1/4 in. quick-connects
Coil Ratings Voltage
24 Vac
