Ball Bearing
The Azure Digi-Motor from Mars is a high efficiency variable speed direct drive blower motor for a multitude of applications. Azure is a replacement for both standard PSC and Genteq Z-13 motors. Motor covers 1/5 HP to 1HP at 115V or 230V and CW or CCW.
Azure features an auto sizing learn mode. In start-up learn mode, Azure runs for approximately 90 seconds measuring the external static pressure of the system application. Azure then assigns torque values to each of it's five speed taps essentially self-programming itself to the correct HP for the application.
If none of the five speeds provides perfect airflow, an optionial (MARS No. 08501) PWM variable speed controller can be added to the motor. This controller provides 2 speed pots (one for Heat and one for Cool) that allow the motor to be set at any speed from 350 RPM to 1400 RPM for perfect comfort.
Unlike other electronically commutated motors, an outboard surge protector is included within the Azure's wire harness. This is a replacable device (MARS No. 08591).
Features:
Outboard replaceable surge protector
Variable speed PWM when used with Mars part no. 08501
600RPM constant fan mode
Reversible rotation-CW or CCW
High Efficiency 85%
Multi-horsepower
Dual Voltage
5 Speeds
Belly band muont
Specifications:
Class "B" insulation
48 Frame
Thermal overload protected
Operating temperature range: -20 degrees C to 55 degrees C (-4 degrees F to 131 degrees F)
UL and CSA recognized
Volts: 115/230
HP: 1/5 to 1/2
Amps: 6.4/3.8
RPM: 1050
Rotation: Reversible
Cross Reference to Competitive ECM Products
Mars No. 10860 -
Century/AO Smith: CS1056, CSL1056,
US Motors/Emerson: 5522ET, 5532ET, 5542ET (1/3 HP & 1/2 HP), 5552ET (1/2 HP)
GE/Genteq: 6001, 6002, 6005, 6103E, 6203E, 6105E, 6205E
