UEI DT302 Digital Temperature Logger Thermometer NEW

Hover over image to zoom

  • Image 1
SKU:
UEID32
Availability:
Usually ships within 24 hours

Temporarily Out of Stock

 Product Description

UEI DT302 Apollo 2 Digital Temperature Logger offers logging capabilities with 9,999 memory positions, monitoring and uploading data to a computer via USB can be routine, helping to analyze system performance trends with the included software. This digital temperature logger features an amber backlit display that offers large easy-to-read digits.

Features

  • Dual Thermocouple inputs
  • Temp range -346 to +2192F (J)
  • Temp range -328 to +2498F (K)
  • Data logging
  • 9,999 Memory positions
  • USB interface (software included)
  • Thermocouple temperature offset
  • MIN, MAX, AVG & Hold
  • Differential T1-T2
  • Probe Storage
  • 5 year limited warranty

Safety Compliance

  • IP67
  • Water submersion (3’ for 30 min.)
  • High pressure dust resistance
  • (max depression of 20 mbar for 8 hours)
  • CAT 1 Overvoltage
  • CE Certified

Accessories included

  • 2 K type probes with lead wraps
  • 2 AAA batteries
  • Quick Start Guide
  • Owners Manual

Measurement Range: J-Type: -346° to +2192°F (-210° to +1200°C); K-Type: -328° to +2498°F (-200° to +1370°C); T-Type: -418° to +752°F (-250° to +400°C); E-Type: -238° to +1832°F (-150° to +1000°C)
Display Resolution: 0.1°F/°C < 1000° 1.0°F/°C ³ 1000°
Accuracy: J, K, T, and E-Type; ±[0.1% +1.0°F (0.5°C)] [Below -148°F (-100°C): add 0.2% of reading for J, K, and E-Type; and 0.1% of reading for T-Type
Temperature Coefficient: 0.01% of reading 0.1°F per °F(+0.05°C per °C) for <+64°F (+18°C) or +82°F (+28°C) [Below -148°F (-100°C): add 0.05% of reading for J, K, and E-type; and 0.1% of reading for T-type
Real Time Clock Tolerance: About 1 second per day
Maximum Differential Common Mode Voltage: 1V (maximum voltage difference between any pair of inputs)
Temperature Scale: ITS-90 (International Temperature Scale of 1990)
Applicable Standards: N.I.S.T. Monograph 175 revised to ITS-90
Battery: 2 x LR03 (AAA) type 1.5V
Dimension: 7.20” (H) x 3.70” (W) x 1.70” (D)
Weight Approx. 16.2 oz
Certification: CE
Safety: IEC 1010-1 (2001), UL 3111-1 (6, 1994), EN 61010-1 (2001), CSA C22.2 No. 1010.1 (1992)
CAT I: Over Voltage (Installation) CATEGORY I, Pollution Degree 2 per IEC 1010-1
Compliance: IEC 60529: IP67 (Ingress Protection rating) Water Immersion (3’ up to 30 min) No ingress of dust (20mBar up to 8 hrs.)
